15" Slim Line Ties

Our Slim Line Ties feature an overall strap length of 15" (381mm). Their small heads and narrow cross sections make them a good choice for use in limited space.

Also available with an overall strap length of 6" (152.4mm) and 8" (203.3mm).

Attribute
Specifications
Bundle Diameter0.06" -4.00" (1.6mm - 101.6mm)
Width0.14" (3.6mm)
Thickness0.055" / 1.4mm
Minimum Tensile Loop Strength40 lbf. (178 N)
Strap Length15.0" / 381mm

*M = 1000

Part #Environmental RequirementsColorOperating TemperatureQuantity Per Bag*
10335-0General Purpose
Natural-40 to 85°C / -40 to 185°F
100
10336-0Heat Stabilized
Black-40 to 105°C / -40 to 221°F
1M
10338-0General Purpose
Natural-40 to 85°C / -40 to 185°F
100
10339-0 Heat Stabilized
Black-40 to 105°C / -40 to 221°F
100
Part #Panduit Cross ReferenceThomas and Betts Cross Reference
10335-0PLT4I-MTY244M
10336-0 TY244MX
10338-0PLT4I-CTY5244M
10339-0  TY5244MX
