08400-0

5.5" INTERMEDIATE, NAT

This Intermediate Cable Tie features an overall strap length of 5.5"(139.7mm). It is designed for use in heavier applications, having a minimum tensile loop strength of 40 lbf. (178 N). It's also heat stabilized which is perfect for use in high temperature applications.

Attribute
Specifications
Bundle Diameter0.06" - 1.25 (1.6mm - 31.8mm)
Environmental RequirementsHeat Stabilized
Width0.13" (3.3mm)
Thickness0.048" (1.2mm)
Minimum Tensile Loop Strength40 lbf. (178 N)
Strap Length5.5" (139.7mm)
ColorBlack
Operating Temperature -40 to 105°C / -40 to 221°F
Quantity Per Bag*1M
Quantity Per Case*5M
Panduit Cross ReferencePLT1.51-M31
Thomas and Betts Cross ReferenceTYH24M

*M = 1000
